Advanced Matplotlib Techniques for Data

Advanced Matplotlib: Color Maps, Annotations, Subplots, 3D Plots, Contours, Heatmaps, and Pandas Plot

Basic Matplotlib helps you draw simple charts.

Advanced Matplotlib helps you explain data clearly.

In this guide, you will move from single charts to richer analytical visuals:

colored scatter plots
color maps and colorbars
transparency with alpha
larger figure sizes
annotations and text labels
horizontal and vertical reference lines
subplots with shared axes
custom figure layouts with add_subplot
3D scatter plots
3D line plots
3D surface plots
contour plots
heatmaps
Pandas .plot() shortcuts

The examples use original synthetic datasets, not copied notebook or public course data.

Files Used In This Guide

Use these CSV files:

matplotlib_advanced_energy_plants.csv
matplotlib_advanced_stock_monthly.csv

They are small enough to inspect manually but rich enough for advanced visualization practice.

What You Will Learn

By the end, you should be able to:

color scatter points by a third variable
choose and apply Matplotlib color maps
add a colorbar to explain encoded colors
use alpha to handle overlapping points
change figure size and resolution
place text labels on selected points
annotate specific insights with arrows
add axhline and axvline reference lines
create one-row, one-column, and grid subplots
use sharex and sharey
use fig.add_subplot
build 3D scatter, line, and surface plots
convert 3D surfaces into 2D contour plots
create heatmaps with imshow
use Pandas .plot() for quick visual exploration
solve advanced visualization practice problems

1. Setup

python

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt

Load the datasets:

python

plants = pd.read_csv("matplotlib_advanced_energy_plants.csv")
stocks = pd.read_csv("matplotlib_advanced_stock_monthly.csv")

stocks["date"] = pd.to_datetime(stocks["date"])

print(plants.head())
print(stocks.head())

The plants table contains energy plant performance metrics.

The stocks table contains monthly close price and volume for five fictional tickers in 2021.

2. Colored Scatter Plots

A basic scatter plot uses two numeric columns.

A colored scatter plot adds a third variable using color.

Example:

x-axis: monitored capacity
y-axis: actual energy output
color: availability percentage

python

plt.figure(figsize=(8, 5))
plt.scatter(
    plants["rated_capacity_mw"],
    plants["actual_mu"],
    c=plants["availability_pct"],
)
plt.title("Capacity vs Actual Output")
plt.xlabel("Rated Capacity (MW)")
plt.ylabel("Actual Output (MU)")
plt.show()

The chart works, but the colors are not explained yet.

3. Color Maps And Colorbars

A color map converts numbers into colors.

python

plt.figure(figsize=(8, 5))
points = plt.scatter(
    plants["rated_capacity_mw"],
    plants["actual_mu"],
    c=plants["availability_pct"],
    cmap="viridis",
)
plt.colorbar(points, label="Availability (%)")
plt.title("Capacity vs Output Colored By Availability")
plt.xlabel("Rated Capacity (MW)")
plt.ylabel("Actual Output (MU)")
plt.grid(True, alpha=0.25)
plt.show()

Good color maps for continuous values:

python

"viridis"
"plasma"
"cividis"
"magma"
"inferno"

Avoid using rainbow-style color maps for serious analytical work unless you have a specific reason. They can make differences look stronger than they are.

4. Alpha For Overlapping Points

alpha controls transparency.

Use it when points overlap.

python

plt.figure(figsize=(8, 5))
plt.scatter(
    plants["planned_maintenance_mw"],
    plants["unplanned_outage_mw"],
    c=plants["emission_score"],
    cmap="plasma",
    alpha=0.7,
    s=90,
)
plt.colorbar(label="Emission Score")
plt.title("Maintenance Load vs Unplanned Outage Load")
plt.xlabel("Planned Maintenance Load (MW)")
plt.ylabel("Unplanned Outage Load (MW)")
plt.grid(True, alpha=0.25)
plt.show()

s controls marker size.

alpha=0.7 makes dense regions easier to read.

5. Plot Size

Use figsize when labels, legends, or annotations need room.

python

plt.figure(figsize=(12, 6))
plt.scatter(
    plants["rated_capacity_mw"],
    plants["actual_mu"],
    c=plants["demand_index"],
    cmap="cividis",
    s=100,
)
plt.colorbar(label="Demand Index")
plt.title("Large Scatter Plot For Presentation")
plt.xlabel("Rated Capacity (MW)")
plt.ylabel("Actual Output (MU)")
plt.grid(True, alpha=0.25)
plt.show()

figsize=(12, 6) means 12 inches wide and 6 inches tall.

For saved images, combine figsize and dpi.

python

plt.figure(figsize=(12, 6), dpi=140)

6. Text Labels

Text labels help identify important points.

Do not label every point unless the chart is very small.

python

top_capacity = plants.nlargest(5, "rated_capacity_mw")

plt.figure(figsize=(10, 6))
plt.scatter(plants["rated_capacity_mw"], plants["actual_mu"], alpha=0.6)

for _, row in top_capacity.iterrows():
    plt.text(
        row["rated_capacity_mw"] + 8,
        row["actual_mu"],
        row["plant_name"],
        fontsize=8,
    )

plt.title("Top Capacity Plants Labeled")
plt.xlabel("Rated Capacity (MW)")
plt.ylabel("Actual Output (MU)")
plt.grid(True, alpha=0.25)
plt.show()

Use plt.text(x, y, label) for simple labels.

7. Annotations

Annotations are better when you want to call out one insight.

python

high_forced = plants.loc[plants["unplanned_outage_mw"].idxmax()]

plt.figure(figsize=(10, 6))
plt.scatter(
    plants["planned_maintenance_mw"],
    plants["unplanned_outage_mw"],
    c=plants["availability_pct"],
    cmap="viridis",
    s=90,
)
plt.colorbar(label="Availability (%)")
plt.annotate(
    "Highest forced maintenance",
    xy=(high_forced["planned_maintenance_mw"], high_forced["unplanned_outage_mw"]),
    xytext=(high_forced["planned_maintenance_mw"] - 80, high_forced["unplanned_outage_mw"] + 12),
    arrowprops={"arrowstyle": "->", "color": "white"},
)
plt.title("Maintenance Risk View")
plt.xlabel("Planned Maintenance Load (MW)")
plt.ylabel("Unplanned Outage Load (MW)")
plt.grid(True, alpha=0.25)
plt.show()

Use annotations to explain why a point matters.

8. Horizontal And Vertical Reference Lines

Reference lines help compare values to an average, target, or threshold.

python

x_avg = plants["rated_capacity_mw"].mean()
y_avg = plants["actual_mu"].mean()

plt.figure(figsize=(9, 5))
plt.scatter(plants["rated_capacity_mw"], plants["actual_mu"], alpha=0.75)
plt.axvline(x_avg, color="orange", linestyle="--", label="Avg capacity")
plt.axhline(y_avg, color="green", linestyle="--", label="Avg output")
plt.title("Capacity vs Output With Average Lines")
plt.xlabel("Rated Capacity (MW)")
plt.ylabel("Actual Output (MU)")
plt.legend()
plt.grid(True, alpha=0.25)
plt.show()

Use:

axvline for vertical reference lines
axhline for horizontal reference lines

9. Object-Oriented Matplotlib

For advanced plots, prefer fig, ax = plt.subplots().

python

fig, ax = plt.subplots(figsize=(9, 5))

ax.scatter(plants["rated_capacity_mw"], plants["actual_mu"])
ax.set_title("Object-Oriented Scatter Plot")
ax.set_xlabel("Rated Capacity (MW)")
ax.set_ylabel("Actual Output (MU)")
ax.grid(True, alpha=0.25)

plt.show()

This style scales better for subplots.

Important mappings:

`plt` style	Object-oriented style
`plt.title()`	`ax.set_title()`
`plt.xlabel()`	`ax.set_xlabel()`
`plt.ylabel()`	`ax.set_ylabel()`
`plt.grid()`	`ax.grid()`
`plt.legend()`	`ax.legend()`

10. Basic Subplots

Create two charts in one row.

python

fig, axes = plt.subplots(nrows=1, ncols=2, figsize=(12, 5))

axes[0].scatter(plants["rated_capacity_mw"], plants["actual_mu"], alpha=0.7)
axes[0].set_title("Capacity vs Output")
axes[0].set_xlabel("Capacity (MW)")
axes[0].set_ylabel("Actual Output (MU)")
axes[0].grid(True, alpha=0.25)

axes[1].scatter(plants["planned_maintenance_mw"], plants["unplanned_outage_mw"], alpha=0.7, color="orange")
axes[1].set_title("Maintenance vs Unplanned Outage Load")
axes[1].set_xlabel("Maintenance (MW)")
axes[1].set_ylabel("Unplanned Outage Load (MW)")
axes[1].grid(True, alpha=0.25)

plt.tight_layout()
plt.show()

axes is an array of subplot objects.

11. Subplots With Shared Axes

Use shared axes when charts use the same scale.

python

fig, axes = plt.subplots(nrows=2, ncols=1, figsize=(10, 7), sharex=True)

for ticker, frame in stocks.groupby("ticker"):
    axes[0].plot(frame["date"], frame["close"], label=ticker)
    axes[1].plot(frame["date"], frame["volume"], label=ticker)

axes[0].set_title("Monthly Close Price")
axes[0].set_ylabel("Close")
axes[0].legend(ncol=5, fontsize=8)
axes[0].grid(True, alpha=0.25)

axes[1].set_title("Monthly Volume")
axes[1].set_xlabel("Date")
axes[1].set_ylabel("Volume")
axes[1].grid(True, alpha=0.25)

plt.tight_layout()
plt.show()

sharex=True keeps both charts aligned on the same time axis.

12. 2x2 Dashboard

python

fig, axes = plt.subplots(nrows=2, ncols=2, figsize=(12, 9))

axes[0, 0].scatter(plants["rated_capacity_mw"], plants["actual_mu"], alpha=0.7)
axes[0, 0].set_title("Capacity vs Output")

axes[0, 1].hist(plants["availability_pct"], bins=8, edgecolor="black")
axes[0, 1].set_title("Availability Distribution")

fuel_output = plants.groupby("fuel_type")["actual_mu"].sum().sort_values()
axes[1, 0].barh(fuel_output.index, fuel_output.values)
axes[1, 0].set_title("Output By Fuel Type")

region_maintenance = plants.groupby("region")["planned_maintenance_mw"].mean()
axes[1, 1].bar(region_maintenance.index, region_maintenance.values, color="purple")
axes[1, 1].set_title("Average Maintenance By Region")
axes[1, 1].tick_params(axis="x", rotation=25)

for ax in axes.ravel():
    ax.grid(True, alpha=0.2)

plt.tight_layout()
plt.show()

Use axes[row, col] for grid layouts.

Use axes.ravel() when you want to loop over every subplot.

13. `fig.add_subplot`

add_subplot gives you manual control over subplot placement.

python

fig = plt.figure(figsize=(12, 7))

ax1 = fig.add_subplot(2, 2, 1)
ax2 = fig.add_subplot(2, 2, 2)
ax3 = fig.add_subplot(2, 1, 2)

ax1.scatter(plants["rated_capacity_mw"], plants["actual_mu"])
ax1.set_title("Capacity vs Output")

ax2.hist(plants["availability_pct"], bins=8, edgecolor="black")
ax2.set_title("Availability Distribution")

for ticker, frame in stocks.groupby("ticker"):
    ax3.plot(frame["date"], frame["close"], label=ticker)
ax3.set_title("Close Price Trend")
ax3.legend(ncol=5, fontsize=8)

plt.tight_layout()
plt.show()

The call fig.add_subplot(2, 2, 1) means:

make a 2-row by 2-column grid
place this subplot in position 1

14. 3D Scatter Plot

3D plotting requires a 3D projection.

python

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")

points = ax.scatter(
    plants["rated_capacity_mw"],
    plants["planned_maintenance_mw"],
    plants["unplanned_outage_mw"],
    c=plants["availability_pct"],
    cmap="viridis",
    s=70,
)

ax.set_title("3D Maintenance View")
ax.set_xlabel("Capacity (MW)")
ax.set_ylabel("Maintenance (MW)")
ax.set_zlabel("Unplanned Outage Load (MW)")
fig.colorbar(points, ax=ax, label="Availability (%)", shrink=0.7)

plt.show()

3D charts are useful for exploration, but they can be harder to read in reports.

15. 3D Line Plot

python

t = np.linspace(0, 8 * np.pi, 250)
x = np.cos(t)
y = np.sin(t)
z = t

fig = plt.figure(figsize=(8, 7))
ax = fig.add_subplot(111, projection="3d")
ax.plot(x, y, z, linewidth=2)
ax.set_title("3D Spiral Line")
ax.set_xlabel("x")
ax.set_ylabel("y")
ax.set_zlabel("time")
plt.show()

3D line plots are good for paths, trajectories, or time-based movement through two measurements.

16. 3D Surface Plot

Surface plots show a computed value over a 2D grid.

python

x = np.linspace(-4, 4, 80)
y = np.linspace(-4, 4, 80)
xx, yy = np.meshgrid(x, y)
zz = np.sin(xx) + np.cos(yy)

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")
surface = ax.plot_surface(xx, yy, zz, cmap="viridis", edgecolor="none")
ax.set_title("3D Surface: sin(x) + cos(y)")
ax.set_xlabel("x")
ax.set_ylabel("y")
ax.set_zlabel("z")
fig.colorbar(surface, ax=ax, shrink=0.7)
plt.show()

np.meshgrid creates a coordinate grid.

plot_surface draws the 3D surface.

17. Another Surface Example

python

x = np.linspace(1, 8, 80)
y = np.linspace(1, 8, 80)
xx, yy = np.meshgrid(x, y)
zz = np.sin(xx) + np.log(yy)

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")
surface = ax.plot_surface(xx, yy, zz, cmap="plasma", edgecolor="none")
ax.set_title("3D Surface: sin(x) + log(y)")
ax.set_xlabel("x")
ax.set_ylabel("y")
ax.set_zlabel("z")
fig.colorbar(surface, ax=ax, shrink=0.7)
plt.show()

Use valid ranges for functions like log. That is why this example starts at 1, not 0.

18. Contour Plots

A contour plot represents a 3D surface on a 2D plane.

python

x = np.linspace(-4, 4, 80)
y = np.linspace(-4, 4, 80)
xx, yy = np.meshgrid(x, y)
zz = np.sin(xx) + np.cos(yy)

plt.figure(figsize=(8, 6))
contours = plt.contour(xx, yy, zz, levels=12, cmap="viridis")
plt.clabel(contours, inline=True, fontsize=8)
plt.title("Contour Plot")
plt.xlabel("x")
plt.ylabel("y")
plt.show()

Contour lines connect points with equal z values.

19. Filled Contour Plot

python

plt.figure(figsize=(8, 6))
filled = plt.contourf(xx, yy, zz, levels=20, cmap="viridis")
plt.colorbar(filled, label="z value")
plt.title("Filled Contour Plot")
plt.xlabel("x")
plt.ylabel("y")
plt.show()

Use contourf when you want color-filled regions.

20. Heatmap

Heatmaps are useful for matrix-like data.

Example: average actual output by region and fuel type.

python

heat = plants.pivot_table(
    index="region",
    columns="fuel_type",
    values="actual_mu",
    aggfunc="mean",
).fillna(0)

plt.figure(figsize=(8, 5))
plt.imshow(heat, cmap="YlGnBu")
plt.colorbar(label="Average Actual Output (MU)")
plt.xticks(np.arange(len(heat.columns)), heat.columns, rotation=25, ha="right")
plt.yticks(np.arange(len(heat.index)), heat.index)
plt.title("Average Output Heatmap")
plt.tight_layout()
plt.show()

imshow displays a 2D matrix as an image.

Use xticks and yticks to make matrix labels readable.

21. Heatmap With Cell Labels

python

plt.figure(figsize=(8, 5))
plt.imshow(heat, cmap="YlGnBu")
plt.colorbar(label="Average Actual Output (MU)")
plt.xticks(np.arange(len(heat.columns)), heat.columns, rotation=25, ha="right")
plt.yticks(np.arange(len(heat.index)), heat.index)

for row in range(heat.shape[0]):
    for col in range(heat.shape[1]):
        plt.text(col, row, f"{heat.iloc[row, col]:.0f}", ha="center", va="center", color="black")

plt.title("Average Output Heatmap With Labels")
plt.tight_layout()
plt.show()

Cell labels are helpful for small matrices.

For large matrices, labels can become noisy.

22. Pandas `.plot()`

Pandas can call Matplotlib behind the scenes.

This is useful for quick exploration.

22.1 Series Plot

python

stocks.groupby("ticker")["close"].mean().sort_values().plot(kind="barh", figsize=(8, 4))
plt.title("Average Close Price By Ticker")
plt.xlabel("Average Close")
plt.tight_layout()
plt.show()

Explanation

Groups stock data by ticker symbol and calculates the mean closing price for each group
Sorts the results in ascending order to arrange bars from lowest to highest average price
Generates a horizontal bar chart visualization using matplotlib with specified figure dimensions
Adds appropriate title and axis labels for clear data presentation
Applies tight layout formatting to ensure proper spacing and display of chart elements

22.2 DataFrame Line Plot

python

close_wide = stocks.pivot(index="date", columns="ticker", values="close")

close_wide.plot(figsize=(10, 5), marker="o")
plt.title("Monthly Close Price By Ticker")
plt.xlabel("Date")
plt.ylabel("Close Price")
plt.grid(True, alpha=0.25)
plt.tight_layout()
plt.show()

Explanation

Transforms the stocks DataFrame from long format to wide format using pivot, where dates become rows, tickers become columns, and closing prices are the values
Generates a line plot with markers showing the monthly closing price trends for each stock ticker over time
Applies formatting including figure size, title, axis labels, grid lines with transparency, and automatic layout adjustment for better visualization
Displays the resulting plot to visualize price movements and compare performance across different stock symbols
Uses matplotlib's plotting functionality to create an interactive chart that helps analyze stock market data patterns

22.3 Pandas Scatter Plot

python

stocks.plot(
    kind="scatter",
    x="close",
    y="volume",
    figsize=(8, 5),
    alpha=0.7,
)
plt.title("Close Price vs Volume")
plt.grid(True, alpha=0.25)
plt.show()

Explanation

Generates a scatter plot showing the correlation between stock closing prices (x-axis) and trading volume (y-axis) using pandas plotting functionality
Sets figure dimensions to 8x5 inches with 70% transparency for data points to improve visibility of overlapping observations
Adds a title "Close Price vs Volume" and includes a subtle grid overlay with 25% opacity for easier data reading
Displays the final visualization with plt.show() to render the scatter plot in the output
Uses matplotlib's plt module for additional formatting elements like titles and grid styling

22.4 Pandas Histogram

python

stocks["return_pct"].plot(kind="hist", bins=10, edgecolor="black", figsize=(8, 4))
plt.title("Monthly Return Distribution")
plt.xlabel("Return (%)")
plt.show()

Explanation

Plots the distribution of monthly stock returns using a histogram with 10 bins to categorize the data
Adds black edges around each histogram bar for better visual separation and clarity
Sets the figure size to 8x4 inches for optimal display of the distribution chart
Includes appropriate title and x-axis label to clearly communicate what the visualization represents
Displays the final histogram plot showing how monthly returns are distributed across different percentage ranges

22.5 Pandas Pie Chart

python

fuel_counts = plants["fuel_type"].value_counts()

fuel_counts.plot(kind="pie", autopct="%0.1f%%", figsize=(6, 6))
plt.title("Fuel Type Share")
plt.ylabel("")
plt.show()

Explanation

The code counts the frequency of each unique fuel type in the plants DataFrame using value_counts() method
It generates a pie chart visualization showing the percentage distribution of different fuel types with automatic percentage labels
The chart is configured with a 6x6 figure size and includes a title "Fuel Type Share" without a y-axis label
The visualization helps identify the relative proportions of various fuel sources used in the power plants dataset
The resulting pie chart displays each fuel type as a slice representing its share of the total plant fleet

For quick work, Pandas .plot() is convenient.

For polished visuals, the object-oriented Matplotlib API gives more control.

23. Practice Problems

Use the two CSV files from this guide.

Problem 1: Two Subplots With Average Reference Lines

Create a figure with two charts:

Chart 1: rated_capacity_mw vs planned_maintenance_mw
Chart 2: rated_capacity_mw vs actual_mu
use only the top 5 most frequent regions by row count
draw average x and y lines on both charts

python

top_regions = plants["region"].value_counts().head(5).index
sample = plants[plants["region"].isin(top_regions)]

fig, axes = plt.subplots(1, 2, figsize=(13, 5))

axes[0].scatter(sample["rated_capacity_mw"], sample["planned_maintenance_mw"], alpha=0.75)
axes[0].axvline(sample["rated_capacity_mw"].mean(), color="orange", linestyle="--")
axes[0].axhline(sample["planned_maintenance_mw"].mean(), color="green", linestyle="--")
axes[0].set_title("Capacity vs Maintenance")
axes[0].set_xlabel("Rated Capacity (MW)")
axes[0].set_ylabel("Planned Maintenance Load (MW)")
axes[0].grid(True, alpha=0.25)

axes[1].scatter(sample["rated_capacity_mw"], sample["actual_mu"], alpha=0.75, color="purple")
axes[1].axvline(sample["rated_capacity_mw"].mean(), color="orange", linestyle="--")
axes[1].axhline(sample["actual_mu"].mean(), color="green", linestyle="--")
axes[1].set_title("Capacity vs Output")
axes[1].set_xlabel("Rated Capacity (MW)")
axes[1].set_ylabel("Actual Output (MU)")
axes[1].grid(True, alpha=0.25)

plt.tight_layout()
plt.show()

Explanation

Filters the plants dataset to include only the top 5 most common regions based on frequency counts
Creates two side-by-side scatter plots comparing rated capacity against planned maintenance load and actual output measurements
Adds mean lines for both x and y axes in each subplot to visualize central tendencies
Configures plot titles, axis labels, and grid formatting for improved readability and analysis
Uses matplotlib's subplots functionality to display both visualizations in a single figure layout

Problem 2: 3D Scatter Plot

Create a 3D scatter plot using:

x: rated_capacity_mw
y: planned_maintenance_mw
z: unplanned_outage_mw
color: availability_pct

python

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")

points = ax.scatter(
    plants["rated_capacity_mw"],
    plants["planned_maintenance_mw"],
    plants["unplanned_outage_mw"],
    c=plants["availability_pct"],
    cmap="viridis",
    s=80,
)

ax.set_title("3D Plant Outage Scatter")
ax.set_xlabel("Capacity (MW)")
ax.set_ylabel("Maintenance (MW)")
ax.set_zlabel("Unplanned Outage Load (MW)")
fig.colorbar(points, ax=ax, shrink=0.7, label="Availability (%)")
plt.show()

Explanation

Creates a 3D visualization showing the relationship between rated capacity, planned maintenance, and unplanned outages for power plants
Uses color mapping to represent availability percentages across the scatter points, with viridis colormap for clear visual distinction
Sets appropriate axis labels and title to clearly indicate what each dimension represents in the power plant data
Adds a colorbar to show the correlation between point colors and availability percentages
Displays the final 3D scatter plot with properly sized markers and adjusted color bar positioning

Problem 3: Surface Plot

Plot this equation:

text

z = sin(x) + cos(y)

python

x = np.linspace(-5, 5, 100)
y = np.linspace(-5, 5, 100)
xx, yy = np.meshgrid(x, y)
zz = np.sin(xx) + np.cos(yy)

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")
surface = ax.plot_surface(xx, yy, zz, cmap="viridis", edgecolor="none")
ax.set_title("Surface: sin(x) + cos(y)")
fig.colorbar(surface, ax=ax, shrink=0.7)
plt.show()

Explanation

Generates a grid of x and y coordinates ranging from -5 to 5 with 100 points each using np.linspace and np.meshgrid
Computes the z-values as the sum of sine of x values and cosine of y values across the entire grid
Creates a 3D surface plot using matplotlib's plot_surface function with a viridis color map and removes edge lines for smoother appearance
Adds a title "Surface: sin(x) + cos(y)" and includes a color bar to indicate z-value intensity levels
Displays the resulting 3D visualization with proper figure sizing and axis labeling

Problem 4: 3D Contour Plot

python

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")
contours = ax.contour3D(xx, yy, zz, 40, cmap="viridis")
ax.set_title("3D Contour: sin(x) + cos(y)")
ax.set_xlabel("x")
ax.set_ylabel("y")
ax.set_zlabel("z")
plt.show()

Explanation

Creates a 3D figure with specified dimensions (9x7 inches) and adds a 3D subplot using the '3d' projection
Generates 40 contour levels from the 3D data arrays (xx, yy, zz) using the 'viridis' colormap to visualize the mathematical function sin(x) + cos(y)
Sets descriptive labels for all three axes (x, y, z) along with a title identifying the plotted function
Displays the final 3D contour visualization with proper axis labeling and color mapping

Problem 5: Filled 2D Contour Plot

python

plt.figure(figsize=(8, 6))
filled = plt.contourf(xx, yy, zz, levels=25, cmap="viridis")
plt.colorbar(filled, label="z value")
plt.title("Filled Contour: sin(x) + cos(y)")
plt.xlabel("x")
plt.ylabel("y")
plt.show()

Explanation

Creates a figure window with specified dimensions (8 by 6 inches) for the visualization
Generates a filled contour plot using contourf() with 25 distinct color levels and the viridis colormap to represent z values
Adds a color bar legend to show the relationship between colors and z value ranges
Sets the plot title, x-axis label, and y-axis label for proper documentation and context
Displays the final contour plot visualization with all configured elements

Problem 6: Use Pandas Plot Functions

Create a line chart of close prices.

python

close_wide = stocks.pivot(index="date", columns="ticker", values="close")
close_wide.plot(figsize=(10, 5), marker="o")
plt.title("Ticker Close Prices")
plt.xlabel("Date")
plt.ylabel("Close")
plt.grid(True, alpha=0.25)
plt.tight_layout()
plt.show()

Explanation

Transforms the stocks DataFrame from long format to wide format using pivot, where dates become rows, tickers become columns, and closing prices are the values
Generates a line plot with markers showing the closing price trends for each ticker across the date range
Applies formatting including figure size, title, axis labels, and grid lines to enhance readability of the financial data visualization
Uses tight_layout to ensure proper spacing and prevent label cutoff in the final plot display
Displays the resulting matplotlib chart showing comparative price movements for all tickers over time

Problem 7: Close Price vs Volume For Top 5 Stocks

python

top_tickers = stocks.groupby("ticker")["volume"].sum().nlargest(5).index
sample = stocks[stocks["ticker"].isin(top_tickers)]

fig, ax = plt.subplots(figsize=(9, 6))
for ticker, frame in sample.groupby("ticker"):
    ax.scatter(frame["close"], frame["volume"], label=ticker, alpha=0.75)

ax.set_title("Close Price vs Volume")
ax.set_xlabel("Close Price")
ax.set_ylabel("Volume")
ax.legend()
ax.grid(True, alpha=0.25)
plt.show()

Explanation

Identifies the top 5 stock tickers with highest total trading volume using groupby aggregation and nlargest
Filters the original dataset to include only records from these top volume tickers
Creates a scatter plot showing the relationship between closing price and trading volume for each stock
Applies visual styling including transparency, legends, and grid lines for better data visualization
Displays the resulting plot with appropriate axis labels and title for clear interpretation

Problem 8: 3D Scatter With Synthetic Time Data

python

time = np.linspace(0, 20, 200)
x = np.sin(time)
y = np.cos(time)
z = time

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")
points = ax.scatter(x, y, z, c=z, cmap="plasma")
ax.set_title("3D Time Path")
ax.set_xlabel("sin(time)")
ax.set_ylabel("cos(time)")
ax.set_zlabel("time")
fig.colorbar(points, ax=ax, shrink=0.7, label="time")
plt.show()

Explanation

Generates a time array from 0 to 20 seconds with 200 evenly spaced points using numpy's linspace function
Calculates x, y, and z coordinates as sine, cosine, and time values respectively to create a helical path in 3D space
Creates a 3D scatter plot using matplotlib's 3D projection where color mapping represents the time parameter along the path
Adds proper axis labels and a colorbar to show the time progression through the visualization
Displays the resulting 3D plot showing how sine and cosine values trace out a circular path while time increases linearly

Problem 9: Surface And Contours For A Radial Function

python

x = np.linspace(-6, 6, 120)
y = np.linspace(-6, 6, 120)
xx, yy = np.meshgrid(x, y)
r = np.sqrt(xx**2 + yy**2)
zz = np.sin(r)

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")
ax.plot_surface(xx, yy, zz, cmap="magma", edgecolor="none")
ax.set_title("Surface: sin(radius)")
plt.show()

plt.figure(figsize=(8, 6))
plt.contour(xx, yy, zz, levels=18, cmap="magma")
plt.title("Contour: sin(radius)")
plt.xlabel("x")
plt.ylabel("y")
plt.show()

plt.figure(figsize=(8, 6))
plt.contourf(xx, yy, zz, levels=25, cmap="magma")
plt.colorbar(label="z value")
plt.title("Filled Contour: sin(radius)")
plt.xlabel("x")
plt.ylabel("y")
plt.show()

Explanation

Generates a grid of x and y coordinates spanning from -6 to 6 with 120 points each using numpy's linspace function
Calculates the radial distance from origin for each point and computes the z values using the sine of radius formula
Creates three visualizations showing the same mathematical function: a 3D surface plot, a 2D contour plot, and a filled contour plot
Uses matplotlib's plotting functions to display the mathematical relationship between x, y, and z coordinates in different visual formats
Applies the magma colormap to all plots to provide color gradients that enhance visualization of the function's variation

Problem 10: Surface And Contours For A Log Function

python

x = np.linspace(1, 10, 120)
y = np.linspace(1, 10, 120)
xx, yy = np.meshgrid(x, y)
zz = np.log(xx) + np.sqrt(yy)

fig = plt.figure(figsize=(9, 7))
ax = fig.add_subplot(111, projection="3d")
ax.plot_surface(xx, yy, zz, cmap="cividis", edgecolor="none")
ax.set_title("Surface: log(x) + sqrt(y)")
plt.show()

plt.figure(figsize=(8, 6))
plt.contour(xx, yy, zz, levels=18, cmap="cividis")
plt.title("Contour: log(x) + sqrt(y)")
plt.xlabel("x")
plt.ylabel("y")
plt.show()

plt.figure(figsize=(8, 6))
plt.contourf(xx, yy, zz, levels=25, cmap="cividis")
plt.colorbar(label="z value")
plt.title("Filled Contour: log(x) + sqrt(y)")
plt.xlabel("x")
plt.ylabel("y")
plt.show()

Explanation

Generates a grid of x and y values using linspace and meshgrid to create coordinate arrays for plotting
Computes z values using the mathematical function log(x) + sqrt(y) across the entire grid domain
Creates three different visualizations including a 3D surface plot, a contour plot, and a filled contour plot with consistent color mapping
Uses matplotlib's 3D projection capabilities to render the surface plot with smooth shading and proper axis labeling
Implements multiple contour visualization techniques with varying level counts and color schemes to show different aspects of the function's behavior

24. Advanced Matplotlib Checklist

You are ready to move forward when you can:

explain when color should represent a third variable
add a colorbar when using continuous colors
use alpha for overlapping points
annotate one important point without cluttering the plot
draw average or threshold lines
create subplots with one row, one column, and grids
use sharex and sharey
build 3D scatter and surface plots
convert surfaces into contour plots
create a labeled heatmap
use Pandas .plot() for quick exploration
decide when a complex chart is useful and when it is just decoration

Advanced visualization is not about making charts look complicated.

It is about showing more context without making the reader work harder.

Advanced Matplotlib Techniques for Data Visualization

AI Insights

Frequently Asked Questions

Related Work

FastAPI Browser-Workflow Automation

AI Visibility & SEO Auditing Platform

RAG-Powered Learning Platform with AI Assistant
